APFC System-Vajra
Wall Mounted
Floor Mounted
APFC System-Vajra
RATING 10, 20, 30, 40, 50,60, 75 & 100KVAR @ 440V / 50Hz / 3P3W
RESOLUTION:
10% expandable to 2.5%
Heavy Duty Low Loss Capacitors
CR: 187Hz Detuned reactors for Harmonic prone environment.
CS: Suppression Coils for surge control and general linear load.
2 Years OPERATIONAL WARANTEE.
Technical Specifications
VAJRA , 440V/50Hz/3P3W
| Rating kVAR | Capacitor Banking Configuration (kVAR) | |||||
| WALL MOUNTED | ||||||
| 10 kVAR | 1 | 2 | 2 | 5 | ||
| 20 kVAR | 2 | 4 | 6 | 8 | ||
| 30 kVAR | 2 | 4 | 4 | 10 | 10 | |
| 40 kVAR | 2 | 4 | 4 | 10 | 10 | |
| 50 kVAR | 2 | 4 | 4 | 10 | 10 | 20 |
| FLOOR MOUNTED | ||||||
| 60 kVAR | 2 | 4 | 4 | 10 | 20 | 20 |
| 75 kVAR | 2 | 5 | 5 | 15 | 25 | 25 |
| 100 kVAR | 5 | 5 | 15 | 25 | 25 | 25 |
| Parameter | Description |
| Rated Voltage | : 415V-440V/3P3W |
| Frequency | : 50Hz |
| Rating kVAR | : 10/20/30/40/50/60/75/100 kVAR |
| PF Controller | : TAS make PF controller (Modbus/IoT optional) |
| Contactors | : Capacitor Duty Contactors with reputed make |
| Thyristor Switches | : TAS make Thy-Speed (fast switching application) |
| Capacitors | : Heavy Duty Cylindrical Capacitors rated 440V/50Hz |
| Incoming/Outgoing | : MCCB 25kA as Incomer and HRC fuses for capacitor bank protection |
| Panel Design | : Standard enclosure with Axial flow fan with Louver & Thermostat, separate compartment for capacitor banks and switchgears |
| Protection Class | : IP 40 (IP50/IP65 Optional) |
